Zmods
The Zmod™ family is Digilent's line of peripheral modules that conform to Opal Kelly's SYZYGY specification. Zmods are interface boards that offer modular high-speed I/O capabilities to compatible FPGA host boards.
Software Support
Digilent provides software libraries for interacting with Zmods, documented in the Zmod Base Library User Guide.
List of Zmods
| Image | Name | Sample Rate | Resolution | Specification Versions |
|---|---|---|---|---|
 | Zmod Scope Resource Center (Redirect) | 40 MS/s (1410-40) 105 MS/s (1410-105) 125 MS/s (1410-125) 40 MS/s (1210-40) 125 MS/s (1210-125) 40 MS/s (1010-40) 125 MS/s (1010-125) | 14-bit (1410-40) 14-bit (1410-105) 14-bit (1410-125) 12-bit (1210-40) 12-bit (1210-125) 10-bit (1010-40) 10-bit (1010-125) | SYZYGY Standard 1.1, SYZYGY DNA 1.1 |
 | Zmod AWG Resource Center (Redirect) | 100 MS/s | 14-bit | SYZYGY Standard 1.1, SYZYGY DNA 1.1 |
